GEN-25 Portable Dew Point Analyzer
-
Good long-term stability, high reliability, high precision, long calibration cycle;
-
Dew point value and volume fraction display at the same time (ppm/V), to meet the different needs of users;
-
Built-in large capacity lithium battery, standby time can reach more than 48 hours;
-
Menu lock switch: prevent misoperation to change the analyzer parameters and affect its normal operation;
-
When the dew point value deviates from the alarm value, an alarm will be issued, and the alarm value can be set arbitrarily in the full range.
Principle: Ultra-thin Alumina Capacitive
Measuring Range:
-60°C~+20°C (basic)
-80°C~+20°C (standard)
-100°C~+20°C (extension)
Linear Error: ±3°C(-80~-60°C), ±2°C(-60~+20°C)
Repeatability: ±0.5°C
Zero Drift: ±1%FS/7d
Range Drift: ±1%FS/7d
Response Time:
63%[90%] range at +20°C and 1bar pressure
-60→-20°C Td 5s[10s]
-20→-60°C Td 45s[10min]
Power Supply: AC 100~240V, 50/60Hz
Consumption: <20A
Communication: RS485(standard)/RS232(optional)
Connection Port: DB-15 Female
Ambient Temperature.: 0~+45°C
Ambient Humidity:<90%RH
Sample Gas Pressure: Atmospheric Conditions±10% (Gas outlet should be atmospheric conditions)
