Moisture in Oil and Temperature Transmitter (CI-BM05)
Continuous online measurement of moisture content in oil;
Measuring water activity, can calculate the value of PPM (w) in oil; Measurement of transformer oil, hydraulic oil, lubricating oil, engine oil, diesel oil;
Excellent temperature and pressure resistance and fast response speed;
Innovative temperature compensation algorithm and multipoint temperature compensation check before the factory;
Excellent anti-interference ability.
Water Activity Measuring Range: 0~1aw
Oil Temperature Measurement Range: -40~+100°C
Water Activity Accuracy:
0~0.9, ±0.02
0.9~1.0, ±0.03
Temperature Accuracy:
0~50°C, ±0.3°C (standard)
-40~0°C & +50~+100°C, ±0.5°C (standard)
Temperature accuracy requirements can be customized
Dry to Wet (Typical value): <1 min
Current Output: 4~20mA (3-wire) (range can be changed)
Resolution: 0.002mA
Current Drift with Temperature: 0.01% of span/°C
Load: Maximum 500 Ω
Working Temperature: -20~+70°C
Storage Temperature: -40~+80°C
